Vertical In Situ Sterilizable Magnetic Mixing Glass Fermenter

Vertical in situ sterilizable glass fermenter, beautiful and decent, convenient use, thorough sterilization, safe and reliable with bottom discharge valve.
Request QuotationChat Now
  • Whatsapp

    WhatsApp Chat

  • WeChat

    WeChat Chat



The LBR-XGCAV multifunctional glass biological fermentation system adopts a color touch screen to display all measured values and control parameters, which greatly facilitates the user's operation. 4 peristaltic pumps are installed on the front of the control box, which can replenish the fermenter with acid, alkali, defoamer and medium. Various parameters in fermentation such as pH, DO, temperature and rotational speed can be monitored by the controller, and all data and control parameters can be transmitted to the controller or computer. The structure is compact, and various components can be integrated on the fermentation system. The lower drive magnetic force is indirectly coupled with the mechanical stirring method, the structure is simple, and the operation is stable.

Full volume: 1/3/5/7/10/15/10/15L, stainless steel tank + part of borosilicate glass,

Diameter height ratio: 1:2~3; Liquid coefficient: 70%

Stirring system: Magnetic stirring system, which adopts a strong magnetic mechanical suspension magnetic stirring system (fully sealed, zero leakage, pollution-free, maintenance-free, and suspended magnetic stirring system. The dynamic seal is changed to a static seal, which completely solves the problem of biological product tank culture. The problem of bacterial contamination, there is no thimble at the bottom,) the speed is stable; the inner parts of the tank are all installed on the tank cover, which is very convenient for maintenance and cleaning; the design of the separation of the motor and the tank body greatly reduces the weight of the tank body, making the operation easier and more convenient, saving money Lots of manpower. The magnetic stirring system adopts special permanent magnet material and unique processing technology, which will never fade. The maximum stirring speed will not be lower than the technical requirements during the life of the fermenter. It can also reach the highest speed in high viscosity medium, and can be set automatically The controlled stepless speed regulation range is 50-1200rpm±5rpm.

Ventilation: Rotameter display, adjust the flow of gas according to process requirements

Fermentation pH control function: intelligent PID control, Mettler PH electrode;

Fermentation dissolved oxygen control function: intelligent PID control, METTLER DO electrode;

Temperature control: intelligent PID control, stainless steel jacket electric heating, water cooling

Feeding: a complete feeding system (acid, alkali, foaming enemy, culture agent), which can be fed regularly and quantitatively;

Sterilization: In-situ automatic program sterilization; Inoculation: Alcohol flame inoculation;


Stirring speed: Speed: 50~1000rpm Accuracy: ±1rpm;

PH control: using intelligent PID control, automatic acid/alkali supplementation; range: 2~12ph; control accuracy: ±0.02ph,

DO control: intelligent PID control, which can be related to the feeding speed; range: 0~100%, control accuracy: ±3%;

Temperature control: intelligent PID control; electric heating water cooling; range: cooling water temperature +5~60℃; accuracy: ±0.1℃;

Foam control: electrode detection, peristaltic pump replenishing defoamer, automatic control;

Ventilation: manual adjustment, flow meter display;

Tank pressure: manual adjustment, pressure gauge display; range: 0~0.20Map;

LBR-B control system: German Siemens S7-200 series PLC control system + 7" touch screen display and operation, data processing can be performed. Data can be transferred with a USB flash drive
